Balancing Bird
Basic Information
| MachineLX1 |
| MaterialWood |
| Size176 x 224 mm |
| Software UsedLaserPecker Design Space PC |
| Production Time20 min |
| Engraving Difficulty |
How-to Tutorial
Step 1
Open the file and connect the machine. Begin by placing a 3mm basswood plank on the cutting plate. Adjust the focal length, verify the size, preview the position, and determine the engraving parameters. Once everything is set, proceed to start cutting.
This file is only applicable to 3mm basswood planks. Other thicknesses of wood may not be able to be assembled. Additionally, if you use different materials, you will need to adjust the parameters yourself.
Settings 1
| Engraving MethodLine |
| MaterialWood |
| Power70% |
| Depth80% |
| Pass1 |
| Acceleration Level1 |
| Module Type20 W 450 nm |
Step 2
Assemble the base as shown in the picture, and fill the gaps with glue to make it more secure. Assemble the bird head and body, and then add small pieces of wood for weight at the bottom of the wings. Once the bird are glued, it can be balanced on the base.
Design Files
LaserPecker Design Space V2.5.1 or above is recommended.
